Performance Cylinder Heads
Click on part numbers to add to your order
Part # | Description | List Price | Your Price |
17118 | PAN-SHOVEL CYLINDER HEADS | 1259.99 | 1099.99 |
36012 | HEADBOLT KT PAN&SHL 48UP | 31.99 | 26.99 |
36192 | HD BOLT.KT.12PT.GD8 BBORE | 34.99 | 29.49 |
36277 | BGBORE HEADBOLTS-CHR48-84 | 43.99 | 36.49 |
45900 | S&S SHOVELHEADS STK.BORE O-RNG | 1199.95 | 1061.96 |
45901 | S&S SHOV.HDS 3 5/8 BORE O-RNG | 1199.95 | 1061.96 |
45902 | S&S SHOVELHEADS STK.BORE-BAND | 1199.95 | 1061.96 |
45903 | S&S SHOV.HDS 3 5/8 BORE-BAND | 1199.95 | 1061.96 |
55137 | CYLINDER DOWELS EVO B/T 84UP | 11.99 | 9.99 |
59655 | HEADBOLT(16480-92)B/T & XL 92- | 4.49 | 3.74 |
59657 | CHROME EVO OUTER HEADBOLT16480-92 | 5.99 | 4.99 |
601726 | S&S S/STOCK HEAD KIT 84-99 NAT | 894.95 | 792.03 |
75400 | HEADBOLT INNER (16478-85A) EVO | 3.99 | 3.24 |
75401 | HEADBOLTS B/T 1986-UP (PACK 8) | 21.99 | 18.49 |
85078 | S&S SHOV. HEAD KT 3 5/8 DUAL P | 1229.99 | 1044.99 |
Part # | Description | List Price | Your Price |
010186 | AUTOMATIC COMPRESSION RELEASE | 214.99 | 182.49 |
010187 | 12MM COMPRESSION RELEASE SET | 214.99 | 182.49 |
36053 | EVO CYLINDER BASE STUD SET B/T | 64.99 | 54.99 |
36107 | REPL.CYL.STUDS(8)EVO XL 1986UP | 62.99 | 53.49 |
36142 | BG BORE CYL.BASE NUTS-CHR | 25.99 | 21.99 |
36143 | BG BORE CYL.BASE NUTS-BLK | 22.99 | 19.49 |
36144 | CYL.BASE NUTS-BG.TWN36-77 | 16.99 | 13.99 |
36193 | CYL.BASE STUD SET-B/T 1930-77 | 25.99 | 21.99 |
36194 | CYL.BASE STUD SET-SHOV.1978-84 | 25.99 | 21.99 |
36196 | CYL.BASE WASHERS-CHROME SHOV78-84 | 19.99 | 16.49 |
36197 | CYL.BASE WASHERS-BLK.SHOV78-84 | 12.99 | 10.99 |
55135 | CYLINDER STUDS EVO B/T 84UP(8) | 71.99 | 60.99 |
55136 | CYLINDER STUDS EVO XL 84UP (8) | 71.99 | 60.99 |
601710 | S&S ELECT COMPRESS RELEASE KIT | 289.95 | 249.36 |
687312 | TPE PRO COMPRESSION RELEASE | 29.99 | 24.49 |
687313 | TPE PRO CUSTOM COMP. RELEASE | 31.99 | 26.99 |
699981 | SPYKE B/ON COMP REL SHOVEL | 364.99 | 309.99 |
Part # | Description | List Price | Your Price |
011136 | (4)HD BOLT CVRS B/TW & X/L | 19.99 | 16.99 |
14309 | CHROME EVO HEAD BOLT COVRS L85-UP | 14.99 | 12.49 |
44584 | ELITE CHROME HD BOLT CVR | 64.99 | 54.99 |
